TP-150B - Meanwell - Alimentatore Box Metallo - 150W 5V - Ingresso 100-240 VAC
- Alimentatore MeanWell / Mod. TP-150B
- Potenza 150W
- Tripla Uscita 5V 20A / 12V 7A / -12V 1A
- Vin 90~264VAC
Scheda tecnica
- Tipo Regolazione Uscita
- Tensione Costante / CV
- Tensione Uscita VDC
- 5
- Tensione Uscita 3 VDC
- -12
- Tensione Uscita 2 VDC
- 12
- Tensione Ingresso VAC
- 90~264VAC
90~264VAC - Temperatura di Lavoro
- -10°C / +60°C
- Potenza W
- 150
- PFC
- Si
- Nr. Tensioni Uscita
- 3
- Grado Protezione IP
- IP20
- Garanzia
- 3 Anni
- Formato Meccanico di Montaggio
- Boxed - Montaggio su telaio
- Efficienza
- 77%
- Dimensioni
- 199x99x50mm
- Corrente Uscita mA
- 20000
- Corrente Uscita A
- 20
- Corrente Uscita 3 mA
- 1000
- Corrente uscita 3 A
- 1
- Corrente Uscita 2 mA
- 7000
- Corrente Uscita 2 A
- 7
- Connettore Ingresso
- A Vite
- Connessione Uscita
- A Vite
- Classe Isolamento
- Classe 2
- Certificazioni
- CE, UL
- Applicazioni
- ITE
- Tensione Ingresso VAC (Nominale)
- 220, 110
- Famiglia Prodotto
- TP
- LTT
- 3
- MKP
- YES
- TK-CODE
- 1/0. [4.0.NO.]/LTT-3
- Prezzo listino
- 145.8
