The product image may slightly differ as it is representative of the family and not the model.
Non disponibile - contattaci
Relpower T13 - DMX512 Touch Panel for RGB Control - Black
Description
Main Features
- RGB touch panel for DMX512 and RF 2.4GHz control
- Compatible with DMX decoders from any manufacturer
- Can be used as an RF remote for multiple Skydance LED controllers
- High sensitivity glass surface with central color wheel
- Smooth and precise color control with the touch wheel
- Touch buttons with acoustic feedback and LED indicators
- Available in white or black glass panel version
Technical Specifications
| Model | T13-IT (RGB) |
|---|---|
| Type of light | RGB |
| Number of DMX channels | 12 |
| Exit signal | DMX512, RF 2.4GHz |
| RF distance | 10m (obstacle-free space) |
| Dimming levels | 256 levels (0-100%) |
| Control interface | Touch panel + RF 2.4GHz |
| Input voltage | 100-240VAC |
| Maximum input current | 0.1A |
| Operating temperature | -30°C ~ +55°C |
| Maximum case temperature | +65°C |
| Degree of protection | IP20 |
| Dimensions (LxWxH) | 135 x 100 x 58mm |
| Weight | 0.246kg |
| Certifications | CE, EMC, RED |
| Safety standards | EN 60730-1 |
| Warranty | 5 years |
Control Functionality
- Color wheel: intuitive selection of RGB colors
- Management of 4 independent or synchronized zones
- 10 dynamic preset modes with adjustable speed
- Memorization of personalized scenes
- Adjustment of RGB saturation and brightness
DMX512 Connection Diagram
- Each zone controls 3 DMX channels (R, G, B)
- Zone 1 → Channels 1-3
- Zone 2 → Channels 4-6
- Zone 3 → Channels 7-9
- Zone 4 → Channels 10-12
Connection Diagram (RF 2.4GHz)
- The T13-IT can function as an RF remote control for compatible LED controllers.
- It supports the quick pairing function with RF controllers.
Applications
✅ RGB architectural lighting
✅ DMX512 LED system control
✅ Residential and commercial environments with customized lighting scenarios
✅ Home automation and smart lighting systems
Data sheet
T13-IT-B
- Dimming LED
- Sure, "DMX" is an abbreviation and does not need translation, as it is commonly known internationally, particularly in the context of entertainment and lighting technology.
If you need more context or additional text translated, please provide it! - Led Dimming (interface)
- It seems like "Touch" is already in English. Could you please provide the Italian text that you want translated into English?
- Type
- LED Dimmer
- Input Voltage VAC
- 100~240VAC
- Input Voltage VDC (Range)
- Number of Channels
- 4
