The product image may slightly differ as it is representative of the family and not the model.
Non disponibile - contattaci
FTPC40C POS Power LED Power Supply 40W Constant Current DC Currents 700mA 1050mA
Description
Power supplies for Led POS Power FTPC40C series, 40Watt power, output currents 700mA and 1050mA
The LED power supplies POS Power of the FTPC40C series are entry-level products with a 3-year warranty, whose compact plastic structure makes them suitable even in applications where space is a problem.
The FTPC40C series has a constant current output mode and high voltage, it has an input voltage range from 180 ~ 264VAC and offers models with output currents of 700mA and 1050mA.
The FTPC series is characterized by an ultra-low profile design, which allows it to be installed in tight spaces.
Features:
- LED power supply POS Power
- Constant Current CC output mode
- AC input
- Class II insulation
- Protections from: short circuit, overtemperature
- Free air convection cooling
- Operating temperature: -20°C ~ +45°C
- Compliance with global lighting standards
- Active PFC
- 3-year warranty
- Protection grade IP20
- Dimensions: 159x58x18mm
Applications:
- LED street lighting
- LED lighting
Our rating:
- Reliability
- Price
- Features
- ⚡⚡⚡⚡
- ⚡⚡⚡⚡⚡
- ⚡⚡⚡
Mechanical Features
Main technical specifications
| MODEL | FTPC40C700 | FTPC40C1050 | |||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Type of output | Constant Current / CC | ||||||||||||||||||||||||
| Nominal output current | 700mA | 1050mA | |||||||||||||||||||||||
| Efficiency | 85% | ||||||||||||||||||||||||
| Power | 39.9W | ||||||||||||||||||||||||
| No-load output voltage (max.) | 63VDC | 45VDC | |||||||||||||||||||||||
| Output voltage range | 29~ 57VDC | 19~ 38VDC | |||||||||||||||||||||||
| Input voltage range | 180 ~ 264VAC | ||||||||||||||||||||||||
| AC input current (tip.) | 0.3A / 230VAC | ||||||||||||||||||||||||
| Dimmable | NO | ||||||||||||||||||||||||
| Protection grade | IP20 | ||||||||||||||||||||||||
| Operating temperature | -20°C ÷ 45°C | ||||||||||||||||||||||||
| PFC | YES | ||||||||||||||||||||||||
| Dimensions | 159x58x18mm | ||||||||||||||||||||||||
| Certifications | CE | ||||||||||||||||||||||||
| For purchases and samples | CONTACT US | ||||||||||||||||||||||||
See also:
Download the catalogs of LED power supplies in the attachments tab.
Data sheet
- Output Regulation Type
- Constant Voltage / CV
- Input Voltage VAC
- 180~264VAC
200~240VAC - Operating Temperature
- -4°F / 113°F
- Rating
- 453
- Power W
- 40
- PFC
- YES
- Output Voltage Nr.
- 1
- IP Protection Grade
- IP20
- Warranty
- 3 Years
- Mechanical Mounting Format
- Closed Plastic Container
- Efficiency
- 85%
- Dimensions
- 159x58x18mm
- Output Current mA
- 700
1050 - Output Current A
- 0.7
1.05 - Input Connector
- At Speed
- Output Connection
- At Speed
- Isolation Class
- Class 2
- Certifications
- This is not a sentence in Italian. If you meant "CE" as an abbreviation, it could stand for "Conformità Europea" which translates to "European Conformity" in English. If it's part of a larger sentence or context, please provide more details.
- Applications
- LED Power Supply
- Product Family
- FTPC
